CXJ600 Forming machine
CXJ600 Forming machine
Product Detail:
CXJ600 automatic multi forming machine can automatically perform variors procedures such as meat filling,forming and outputting,and combine a fully automatic prepared food line when connecting with the batter,preduster,fryer,cooker,instant freezer and packing machine.It adopts the method of four-screw feeding system,greatly reduces the cutting of the material,and has better fiatures of high production capacity and stable quality.
Easy and convenient replacement of food and the accurate portion control rdalize the cost control of the production.
Widely handles in the forming procedure of meat,poultry,fish,shrimp and the potato,tuber crops.And it can be applied in the fields of all kind of minced/sliced products for premier meat texture taste.
Safe device: Magnetic protection switch(safe cover).
Parameters:
Mesh belt width |
600mm |
Air pressure/water pressure |
6Bar/2Bar |
Power |
15.12KW |
Capacity |
500-1000kg/h |
Times |
15-60times/minute |
Thickness |
6-40mm |
Error |
≦1% |
Diameter at maximum |
150mm(hamburger patty diameter) |
Filling pressure |
3-15Mpa |
Overall dimension |
3170*1176*2636mm |
Application:
Onion ring, Squid ring, hash brawn, chicken nuggets, burger patty, Cartoon chicken nuggets, etc.
